Specifications

Yokogawa Paperless Recorders SMARTDAC+ GP10/GP20
Standard Ethernet interface
Supports the PROFIBUS-DP and EtherNet/IP protoco

Yokogawa Paperless Recorders SMARTDAC+  GP10/GP20

SMARTDAC+ GP10/GP20 is a portable paperless recorder that retains the core functionality of GX10/GX20 and can be used on the desktop.

• Smart User Interface

• Variety of display function
  Standard display screens clearly indicate channel data with units and tags, plus alarm log, message log, and other event log information.

• Touch screen for intuitive operation
  The new touch screen provides swipe, pinch in/out, and click and drag controls for fast navigation of common display mode functions.

• Supports freehand messages
  Operators can write a free hand text message directly on the touch screen with a pen stylus or fingure.

• Smart Architecture

• Add I/O modules when you need more channels
  The fully modular I/O design allows you to build the system with the channels they need today, and expand the unit’s capability any time in the future by purchasing and installing additional modules.

• Wide-ranging input/outpu specifications
  The 10 channel universal input module measures DC volts, thermocouple, RTD and contact input signals. A 16 channel digital input module and a relya output module are also avaiable.

• Multichannl I/O
  GP10 and GP20 support up to 30 channels and 100 channels of input respectively.

• Smart Functionality

• Direct output to printers
  You can print out reports and snapshots directly from the GP without going throught a PC.

• Convenient report creation function
  Reports can be created automatically using a spreadsheet template created in Excel. You can also output to a PDF file.

• Browser-based real time monitoring
  A web browser can be used to fully access the GP using two operating modes- Data and Configuration.
