LCD display

1999 counts (3-1/2 digits) with bargraph   and backlight

Resolution

1 Volt

AC Voltage range

0 to 480V

ACV frequency range

50/60Hz

DC Voltage range

0 to 690V

Accuracy

ACV ±(1.5%rdg + 5d); DCV ±(1.0%rdg + 3d)

Range selection

Automatic

Max measuring current

≤1.0mA (400VAC); ≤1.5mA (690VDC)

Response time

Updates 2-3 times/sec

Input Impedance

1MΩ (approx)

Continuity test

Range 0 to 200kΩ, guaranteed on <   50kΩ;

Overvoltage protection

480VAC/690VDC

Low impedance test

12-250VAC/DC; impedance <6kΩ;

LCD enable input voltage

>4.5V AC/DC

Operation time:

5s <250V AC/DC

Power supply

2 x "AAA" 1.5V alkaline   batteries

Battery life

Approx. 8 hours continuous use typical

Operating Temperature

14 to 131° F (-10 to 55° C)

Storage Temperature

-22 to 140° F (-30 to 60° C)

Operating Humidity

10 to 85% RH (non-condensing)

Dimensions

9.4 x 3 x 1.6"(240 x 78 x 40mm)

Weight

9.2oz (260G)
